Street Parking Details with 45 Degree Parallel and Perpendicular

Street parking details drawing illustrating diagonal parking 45 degree layout, perpendicular parking arrangement, and parallel parking configuration with accurate dimensional planning. The plan views clearly define parking bay width, vehicle turning clearance, entry and exit direction arrows, and setback distances from roadway edge and boundary wall. Each parking module is drafted with measured stall depth, aisle width, and alignment references to ensure efficient vehicle circulation. The drawing also presents marked pedestrian access and spacing standards for organized urban street planning.
