House Working Layout Plan with Accurate Internal and External

House working layout plan drawing presenting all room dimensions with in to in and out to out measurements clearly marked for construction precision. The plan illustrates complete room configuration including internal wall thickness, door and window positions, and circulation paths. Internal room sizes are dimensioned to define clear usable space, while external dimensions show total building footprint aligned with structural grid lines. Staircases, entry points, and corridor widths are included with precise measurement annotations for accurate site execution.
