Reinforcement Anchor Bolts CAD Drawing Free Download


Description

Anchor bolts projection must be according to design and threads to be clean.The welding quality must be checked using radiographic inspection such as X - Rays or Ultrasonic inspections. Anchor bolts shall be set perpendicular to the theoretical bearing surface unless shown otherwise. All stiffner plates are of 10 mm thickness unless otherwise noted .




File Type: DWG File ID: 164174

Uploaded by:


Komal
India
