Fat Trap Section Detail with Inlet and Outlet Pipes AutoCAD DWG File

This AutoCAD DWG file provides detailed drawings of a fat trap (grease trap), including inlet and outlet pipes, sediment chamber, and structural walls. The drawing shows precise dimensions for chamber depth, pipe diameters, baffle plates, and access covers, offering architects, civil engineers, and builders a comprehensive guide for accurate installation. Each section highlights grease collection, water flow paths, and maintenance access to ensure proper function and compliance with sanitary standards. CAD professionals can efficiently visualize, edit, and integrate this fat trap design into residential or commercial kitchen or plumbing projects. Fully layered and compatible with AutoCAD, Revit, SketchUp, and 3D Max, this DWG supports material estimation, construction planning, and adherence to health and safety regulations.
