Perimeter Boundary Wall Plan Section and Elevation Detail Plan

The drawing presents a perimeter boundary wall construction detail, including plan layout, elevation view, and sectional details used for site enclosure. The plan drawing illustrates the alignment of the boundary wall along the site edge, showing plot divisions marked as section 14 and section 15. The layout indicates the wall length divided into two equal segments, each measuring approximately 9.00 meters, forming a total boundary length of 18.00 meters. The elevation drawing displays the masonry wall structure built using brick units arranged in horizontal courses with reinforced bands integrated across the wall. Structural columns and base supports are also represented to provide stability to the perimeter wall structure.
