Trapeze type hanger detailed.

Here Trapeze type hanger detailed with drawing mention different component of process including lock nut , support nut, rigid insulation , nut fixing nut , fully threaded galvanized steel rod hanger, chilled water pipe with insulation ,galvanized steel u bolt, gauge 20 galvanized sheet shield 300 mm minimum length pipe protection saddle , galvanized steel angle ( 50mm x 50mm x 8mm ) rigid insulation and gap between rigid insulation is (50mm minimum ), insulation protective sheild ,adjustable clevises hanger, expansion sheild, all fabrication sheild should be painted with two coated of zinc chromite. for more information of Trapeze type hanger download this file.
