Explore this<a href="https://cadbull.com/detail/4897/Hotel-Bed-room-design" rel="noopener noreferrer" target="_blank"> Hotel Bedroom Lighting Layout </a>AutoCAD DWG Plan prepared at 1:35 scale for a twin bedroom sea view hotel room. The drawing presents a complete lighting installation layout including LED downlights, MR16 adjustable lights, decorative wall and hanging lamps, LED strip lighting, exhaust fan locations, switches, relays, transformers, thermostat, doorbell, DND controls, cable routing, conduit layout, outlet wiring, MCB box connections, and lighting control points. The plan also shows fixture mounting heights ranging from H plus 0.81 m to H plus 2.08 m, furniture lighting, corridor switching, foyer, bathroom, toilet, bedroom, and shaft lighting arrangements with detailed legends and electrical symbols. This AutoCAD DWG drawing provides an accurate reference for architects, electrical engineers, interior designers, builders, contractors, and MEP professionals involved in hotel lighting design and<a href="https://cadbull.com/detail/30741/Electrical-installation-details-of-building-dwg-file" rel="noopener noreferrer" target="_blank"> electrical installation</a> planning.&nbsp;

Hotel Bedroom Lighting Layout AutoCAD DWG Plan Scale 1 35 Drawing

This<a href="https://cadbull.com/detail/21088/Details-of-crystal-stainless-steel-support" rel="noopener noreferrer" target="_blank"> Steel Support Bracket </a>AutoCAD DWG Drawing provides a comprehensive collection of fabrication drawings for structural steel components used in industrial platforms, roofing systems, equipment supports, and steel framework installations. The drawing set includes a 2500 mm top cap profile, 5210 mm lateral closure panel, folded steel channel section, structural support bracket, 360 mm platform fixing support, reinforcement plate, 200 mm and 400 mm base plates, stepped support plate, and rectangular base plate layouts. Multiple front, side, sectional, and isometric views are included with precise manufacturing information for fabrication and assembly. Important dimensions shown throughout the drawing include 5210 mm overall length, 2575 mm half span, 2500 mm cap length, 380 mm and 150 mm profile heights, 349 mm channel height, 332 mm support height, 308 mm square plate, 360 mm fixing support, 400 mm base plate length, 250 mm support width, 200 mm square plate, 127 mm flange, 154 mm spacing, 140 mm hole spacing, 100 mm hole centers, 65 mm vertical spacing, 60 mm center offset, 40 mm bends, 34 mm folded edge, 25.40 mm plate thickness, 12.70 mm plate thickness, 1.90 mm sheet thickness, 30 mm mounting holes, 20 mm fixing holes, R1, R8, and R10 bend radii, and 10.59° edge bevels.

Steel Support Bracket AutoCAD DWG Drawing With 5210 mm Panel Design

This Steel Panel Assembly AutoCAD DWG Drawing presents a complete set of sheet metal fabrication drawings for industrial and commercial building applications. The drawing package includes a final lining panel, intermediate lining panel, left side closure panel, roof internal panel, ridge cap, support closure profile, and formed sheet metal sections with detailed front views, side views, isometric views, and sectional profiles. It provides precise fabrication information including **2608 mm overall length, 2620 mm panel length, 2500 mm ridge length, 4930 mm profile length, 422 mm profile height, 470 mm section height, 380 mm formed profile, 163.70 mm channel profile, 69 mm flange, 70 mm support, 44 mm base, 17 mm return folds, 23 mm and 35 mm flanges, 30 mm bends, 36 mm offsets, 47.10 mm profile width, 50 mm support width, 5° roof slope, 10° bend angle, R1 and R4 bend radii, and sheet thicknesses of 1.55 mm, 1.90 mm, 1.96 mm, and 2.00 mm.&nbsp;

Steel Sheet Metal Panel Assembly AutoCAD DWG Drawing With 2608 mm Size

This AutoCAD drawing includes detailed fabrication drawings for a 5030mm base plate, 2754mm double door frame assembly, 2680mm lower door profile, 2660mm upper door molding, 2500mm clear opening, 1485mm air conditioning roof flashing, and 285mm duct connection profile. The file contains plan views, elevations, profile sections, bend details, hole positions, welding references, and precise manufacturing dimensions.The drawing also provides sectional <a href="https://cadbull.com/Detail" rel="noopener noreferrer" target="_blank">details </a>for sheet metal fabrication, profile configurations, folded components, door frame assembly, mounting locations, and fabrication notes. It is suitable for <a href="https://cadbull.com/Cad-Architecture" rel="noopener noreferrer" target="_blank">architects</a>, civil engineers, fabrication engineers, BIM professionals, AutoCAD users, Revit modelers, and sheet metal designers requiring accurate CAD documentation for industrial fabrication and construction projects.

5030mm Base Plate and 2754mm Door Frame Fabrication CAD Drawing

A detailed AutoCAD DWG file featuring fabrication drawings for 2608mm lateral closures, 4390mm roof liner profiles, 4380mm intermediate liner, 2500mm ridge flashing, and sheet metal ceiling support components. The drawing package includes front, side, sectional, and isometric views with complete dimensions, bend angles, profile sections, sheet thickness information, fabrication layouts, and manufacturing references. This CAD drawing is suitable for <a href="https://cadbull.com/Cad-Architecture" rel="noopener noreferrer" target="_blank">architects</a>, civil engineers, fabrication professionals, builders, and BIM users working on industrial roofing, metal cladding, and <a href="https://cadbull.com/Structure-detail" rel="noopener noreferrer" target="_blank">structural</a> sheet metal projects requiring precise fabrication and installation documentation.

2608mm and 4390mm Roof Liner Fabrication CAD Drawing Collection

Road Underpass and Retaining Wall Plan AutoCAD DWG Design featuring a detailed transportation infrastructure layout with <a href="https://cadbull.com/detail/109076/Multiple-direction-blocks-and-road-symbols-cad-drawing-details-dwg-file" rel="noopener noreferrer" target="_blank">multi-directional roadway</a> connectivity and structural retaining wall arrangements. This engineering drawing includes underpass carriageway layouts, counterfort retaining walls, cantilever retaining wall sections, approach slab details, median planning, roadway lane geometry, turning curve alignment, traffic circulation routes, and intersection planning. The layout also contains directional road markings towards Hayatabad, Kohat Road, Motorway, Bara Road, and Custom Chowk with dimensional references such as 160.13 m, 130.12 m, 100.75 m, and 75.60 m roadway measurements. This AutoCAD DWG file is useful for civil engineers, transportation planners, highway engineers, architects, infrastructure consultants, and CAD professionals working on road network development, underpass <a href="https://cadbull.com/Construction-Cad-Drawing" rel="noopener noreferrer" target="_blank">construction</a>, urban mobility planning, and retaining wall engineering projects using AutoCAD, Revit, 3d Max, and Google SketchUp software.

Road Underpass and Retaining Wall Plan AutoCAD DWG Design file

A professionally detailed <a href="https://cadbull.com/detail/12554/Office-interior-designhttps://cadbull.com/detail/12554/Office-interior-design" rel="noopener noreferrer" target="_blank">Office Interior</a> Fit Out Layout DWG Plan With Ceiling Design prepared for architects, civil engineers, interior designers, builders, and CAD professionals. This AutoCAD DWG file includes a complete office floor plan layout, furniture layout, partition layout, reflected ceiling plan, targeting layout, and setting out plan with accurate dimensions and workspace arrangements. The drawing contains office cabins, reception area, waiting zone, conference seating, workstations, toilets, pantry area, electrical targeting points, ceiling grid design, lighting placement, partition walls, and circulation planning. The file also includes furniture positioning, interior fit-out measurements, ceiling specifications, material references, symbol legends, and technical detailing for commercial office interior development projects. Suitable for professional drafting and presentation workflows in AutoCAD, Revit, 3ds Max, and Google SketchUp, this office interior <a href="https://cadbull.com/DWG-Blocks" rel="noopener noreferrer" target="_blank">DWG</a> drawing supports commercial planning, interior execution, and workspace renovation documentation. Ideal for office interior design projects, fit-out construction planning, and detailed CAD drafting requirements.

Office Interior Fit Out Layout DWG Plan With Ceiling Designs

<a href="https://cadbull.com/detail/271734/two-storey-residential-building-floor-plan-with-dimensions-dwg-file" rel="noopener noreferrer" target="_blank">Two-storey residential</a> floor plan AutoCAD DWG layout design created for residential renovation and modern house planning projects. This detailed CAD drawing includes ground floor plan and second floor plan with complete room arrangements, master bedroom layout, bedroom planning, living area, dining space, kitchen layout, maid room, master toilet and bath, walk-in closet, open courtyard, patio area, airwell space, stair design, view deck, and circulation planning with dimensional references. The drawing also contains gross floor area details, including 60.10 SQM ground floor area, 60.00 SQM second floor area, and a total gross floor area of 120.10 SQM for organized residential space planning and <a href="https://cadbull.com/Cad-Architecture" rel="noopener noreferrer" target="_blank">architectural </a>documentation. Suitable for architects, civil engineers, interior designers, builders, AutoCAD professionals, Revit users, 3D Max designers, and Google SketchUp experts working on residential drafting and housing development projects. This AutoCAD DWG file supports professional home layout planning with modern residential design standards and detailed floor organization.

Two Storey Residential Floor Plan AutoCAD DWG Layout Designs

This AutoCAD DWG file presents a detailed <a href="https://cadbull.com/detail/253475/Residential-foundation-plan" rel="noopener noreferrer" target="_blank">residential foundation plan</a> with complete structural layout planning for housing and building construction projects. The drawing includes column footing placement, beam grid layout, foundation wall structure, dimension annotations, structural reference points, and footing section details for accurate construction execution. The housing planning DWG design contains clearly marked grid lines, <a href="https://cadbull.com/Construction-Cad-Drawing/Rcc-detail-cad-drawing" rel="noopener noreferrer" target="_blank">reinforced </a>footing arrangements, and measured structural spacing suitable for architects, civil engineers, builders, and construction professionals. This CAD drawing is useful for residential building planning, foundation drafting, structural analysis, and housing development projects requiring accurate foundation plan documentation and AutoCAD structural detailing.

Residential Structural Foundation and Roof Framing DWG Plans

This AutoCAD DWG file presents a comprehensive Wall Reinforcement Detail with clearly defined structural layouts, rebar configurations, and level-based reinforcement specifications. The drawing includes W1 wall reinforcement <a href="https://cadbull.com/Detail" rel="noopener noreferrer" target="_blank">details</a> across multiple levels, such as -30.300 to -15.800, -15.800 to -10.050, and -10.050 to -5.650, ensuring accurate construction referencing. It highlights vertical reinforcement bars like T25 at 200 spacing, T32 at 200, and T14 at 200, along with horizontal bars such as T16 at 200, T20 at 100, and T14 at 200, providing complete detailing for load-bearing wall systems. The file also incorporates wall cross tie details, closed stirrups at T16 at 200, and hook reinforcements noted as T12 at 6 quantity per square meter for enhanced structural stability. Link beam connections and reinforcement continuity are clearly illustrated, making this drawing highly useful for civil engineers, architects, and <a href="https://cadbull.com/Construction-Cad-Drawing" rel="noopener noreferrer" target="_blank">construction </a>professionals. The DWG layout follows precise measurement standards in millimeters and includes grid references, spacing dimensions, and sectional detailing for accurate on-site execution. This Wall Reinforcement Detail DWG Plan is ideal for structural analysis, reinforcement planning, and detailed construction documentation.

Wall Reinforcement Detail DWG Plan With Rebar Sizes And Levels

<a href="https://cadbull.com/detail/265630/Eastern-wc-detail-and-drinking-fountain-detail-dwg-autocad-drawing." rel="noopener noreferrer" target="_blank">A Drinking Dishwash</a> rea Details 2325x2950 750mm Counter DWG Plan showcases a complete layout and sectional detailing of drinking water, handwash, and dishwash areas designed for senior and junior use. The drawing includes a dishwash area of 2325x2950 mm and a store area of 2325x5750 mm with precise counter arrangements at 750 mm and 600 mm heights. It features an RCC counter with an 18 mm-thick granite top, 600x300 mm wall tiles with a 6 mm groove using epoxy grout, and anti-skid 600x600 mm floor tiles. Detailed sections illustrate bottle trap connections, 10 mm mortar layers, sunken slab levels, and fly ash walls of 100 mm and 150 mm thickness. The plan also includes tap placements, water cooler provision with 16 AMP, plate wash area dimensions with multiple 750 mm spacing, and elevation <a href="https://cadbull.com/Detail" rel="noopener noreferrer" target="_blank" style="letter-spacing: 0px; ">details </a>for accurate execution. This AutoCAD DWG file provides clear construction-level detailing for efficient planning of drinking, handwash, and dishwash zones in institutional and commercial <a href="https://cadbull.com/Projects" rel="noopener noreferrer" target="_blank">projects</a>.

Drinking Dishwash Area Details 2325x2950 750mm Counter DWG Plan

This AutoCAD DWG file features a detailed goddess statue DWG drawing with decorative CAD elevation detail, showcasing three intricately designed Hindu deity figures including a seated Ganesha, Lakshmi on lotus base, and Durga with lion mount. The drawing provides high precision linework suitable for architectural and interior decorative applications, with symmetrical proportions and ornamental detailing clearly visible in front elevation views. Each statue includes fine carvings such as jewelry patterns, crown elements, lotus pedestal, weapons, and symbolic objects, making it ideal for temple design, wall panels, and cultural projects. The composition is aligned proportionally for CAD drafting use, ensuring easy scaling and placement in design layouts. This goddess statue DWG drawing with decorative CAD elevation detail is highly useful for architects and designers working on religious structures, offering clean and accurate vector geometry for seamless integration into AutoCAD and 3D modeling workflows.

Goddess Statue DWG Drawing with Decorative CAD Elevation Detail
