Steel Support Bracket AutoCAD DWG Drawing With 5210 mm Panel Design

This Steel Support Bracket AutoCAD DWG Drawing provides a comprehensive collection of fabrication drawings for structural steel components used in industrial platforms, roofing systems, equipment supports, and steel framework installations. The drawing set includes a 2500 mm top cap profile, 5210 mm lateral closure panel, folded steel channel section, structural support bracket, 360 mm platform fixing support, reinforcement plate, 200 mm and 400 mm base plates, stepped support plate, and rectangular base plate layouts. Multiple front, side, sectional, and isometric views are included with precise manufacturing information for fabrication and assembly. Important dimensions shown throughout the drawing include 5210 mm overall length, 2575 mm half span, 2500 mm cap length, 380 mm and 150 mm profile heights, 349 mm channel height, 332 mm support height, 308 mm square plate, 360 mm fixing support, 400 mm base plate length, 250 mm support width, 200 mm square plate, 127 mm flange, 154 mm spacing, 140 mm hole spacing, 100 mm hole centers, 65 mm vertical spacing, 60 mm center offset, 40 mm bends, 34 mm folded edge, 25.40 mm plate thickness, 12.70 mm plate thickness, 1.90 mm sheet thickness, 30 mm mounting holes, 20 mm fixing holes, R1, R8, and R10 bend radii, and 10.59° edge bevels.
