Elevation and plan and section detail of door.

Here elevation and plan and section detail of window. including aluminum door fins ( 35mm x 100mm ) refer to elevation , aluminum frame , polyurethane coating , concrete screed , (20mm ) water proofing layers with protection barriers ,RC slab, including dimension of door detailing , gap between aluminum frame also given in drawing. For more details of door download door section and elevation plan.
