Hot water boiler (side elevation)

 Here Hot water boiler side elevation including plug tees , test valve , return hot water , pipe bracket , supply hot water , union , rotary cup oil burner , breaching , domestic cold water The boiler receives the feed water, which consists of varying proportion of recovered condensed water (return water) and fresh water, which has been purified in varying degrees (make up water). for more details download this file
