Here bar bending details including 16mm ms bar , 6mm fillet welded , 20ms bars 50mm x50mm x 6mm thk Bar bending is a table form data in which various diameters of steel, the shape of bending, length of each bent and straight portions, angles of bending, the total length of each bar, and a number of each type of bar. bar bending schedule is when used along with reinforcement detailed drawing improves the quality of construction, cost and time saving for concrete construction works for more details download this file.
