Reinforcement details of different sections

This architectural drawing is Reinforcement details of different sections. The beam column joint is the crucial zone in a reinforced concrete moment resisting frame. It is subjected to large forces during severe ground shaking and its behavior has a significant influence on the response of the structure. In this drawing there are given different sections with dimensions and reinforcement details. For more details and information download the drawing file.
