First floor Framing plan.


Description

This Architectural Drawing is AutoCAD 2d drawing of First floor Framing plan. Framing plans for floor and roof construction can be derived directly from the floor plan and must incorporate all information that deals with the configuration of the building. Further, the framing plan shows the layout of the supporting features such as bearing walls, columns, beams, and girders. The Floor Framing Plans provide structural information such as the joist location, spacing and direction, as well as the floor heights and stair openings. For more details and information download the drawing file.




File Type: DWG File ID: 255197
