The AutoCAD DWG illustrates two engineering diagrams showing detailed column load equation CAD drawings used for structural analysis. The first diagram represents the Equação e Esquema da Coluna Bi Apoiada, where a uniformly distributed load is applied across a simply supported span. It includes the deflection formula Máxima flecha = 5 × carga × altura? / 384 × E × Jxx, with E indicating the módulo de elasticidade do alumínio and Jxx showing the momento de inércia do perfil. The drawing clearly marks the support points, distribution of load arrows, and mathematical notation, making the structural behavior easy to interpret for design and verification.

The second diagram shows the Equação e Esquema da Coluna Engaste Base com Dilatação Superior, where the base is fixed, and the top allows expansion under the same uniformly distributed load. This condition uses the formula Máxima flecha = 1 × carga × altura? / 384 × E × Jxx, demonstrating reduced deflection compared to the simply supported case. The drawing includes clear load distribution, boundary conditions, and labeled engineering terms to support precise calculations. This DWG is ideal for architects, civil engineers, and structural designers who rely on accurate column deflection analysis for aluminium profile applications and technical documentation.

ba

hyros

Description

DWG

2.2 MB

Structure

Column Details Drawing
