This Architectural Drawing is AutoCAD 2d drawing of Floor reinforcement slab details in AutoCAD, dwg file. Reinforcement should also be placed low enough so saw cutting does not cut the reinforcement. For welded wire reinforcement, the Wire Reinforcement Institute recommends steel placement 2 inches below the surface or within the upper third of the slab thickness, whichever is closer to the surface.
