Reinforcement Bar detail drawing of steel formwork structure with section plan and design in Autocad 2D line plan Drawing.


Description

ferrous Bar details component of steel structure with plan and section design. Detailed mention  about coupe of A-A,A'-A' ,section C-C,C'-C' and section I-I,I'-I' and section F-F. at section A, TB=20,L=1.30,0.85,e=15.section c ,TB=20,L=1.30,0.85,e=15,l=0.5, some joint thickness 5,35,10 , section i and i' reinforcing beam thickness 10*10*155. height=170, diameter of reinforcement bar =15, Section F TB=20,L=2.07,height=60,reinforcing beam bar thickness= 10*10*155.
