Entrance Gate Structure Sonapur College Roof Plan Beam Layout

This AutoCAD drawing presents a detailed entrance gate structure design of Sonapur College including roof plan, footing details, and beam layout with precise dimensions. The file showcases front elevation, plan view, and sectional details that clearly define structural components and construction methodology. It includes top end beam layout, column positioning, and foundation footing design to ensure stability and load distribution. The roofing plan highlights slope, thickness, and material arrangement for proper drainage and durability.
