Dressing Table Working Drawing with Shelves Drawers and Skirting

This AutoCAD drawing provides a complete working detail of a dressing table unit designed for interior furniture execution. The drawing clearly shows a full-height storage cabinet with an overall height of 2400 mm, including precise floor-level references at top and bottom. Veneered MDF panels with solid wood edging are detailed throughout the structure, including side panels, internal shelves, and door faces. The upper storage section includes a fixed shelf positioned at a height of 395 mm with a shelf thickness of 20 mm. Concealed hinge locations are accurately marked to ensure flush alignment of the veneered MDF door face. Dimensional annotations guide proper spacing between shelves, doors, and cabinet frames for accurate fabrication. Keywords included dressing table detail drawing, furniture working drawing.

The lower section illustrates a luggage storage area with a clear height of 320 mm, followed by two drawers with a drawer height of 238 mm each. Drawer guides, drawer fronts, and internal drawer boxes are clearly indicated for smooth operation. A solid wood skirting detail is shown at the base with an 80 mm height, providing a finished floor connection. Additional detailing includes finger pull handles and metal strip inlay for aesthetic enhancement. This dressing table working drawing supports joinery detailing, shop drawing preparation, and on-site installation accuracy. Keywords included dressing table, working drawing, AutoCAD, MDF dressing table section detail, wardrobe dressing unit drawing.
