AutoCAD Modern Compact House Floor Plan with Lounge and Balcony
Description
This AutoCAD modern house floor plan illustrates a smart two-storey compact home design ideal for urban and suburban plots.
The ground floor includes a living area (3.30×4.80 m), dining (4.95×3.00 m), kitchen (3.30×2.70 m), master bedroom (4.50×3.30 m) with attached toilet (3.30×1.85 m), a sit-out (2.70×1.50 m), deck (1.45×1.85 m), and car parking (3.60×4.70 m).
The first floor features two bedrooms (4.00×3.30 m & 3.30×4.50 m), each with attached toilets (2.20×1.50 m), dress areas (1.35×1.50 m), a lounge (4.85×2.95 m), and balconies (3.30×1.20 m & 2.70×1.25 m).
Designed for comfort and efficiency, this layout ensures cross ventilation and elegant glass railing details. Perfect for AutoCAD house plan, modern duplex home design, residential villa layout, and balcony home architecture projects.
