AutoCAD Duplex House Plan 3200 Sqft With Courtyard and Balcony

This AutoCAD DWG duplex house plan presents a beautifully detailed modern layout, covering a total built-up area of 3,200 sq.ft. Designed with precision for comfort, elegance, and spatial efficiency, it offers a perfect blend of functionality and aesthetic balance — making it ideal for architects, civil engineers, interior designers, and builders seeking high-quality residential design resources.

Ground Floor Details

The ground floor includes a formal living area (524×468 cm), dining hall (382×360 cm), family living space (403×382 cm), kitchen (360×396 cm), work area (230×360 cm), bedroom (370×396 cm), and toilets (230×180 cm, 142×230 cm). A porch (568×392 cm) and a sit-out (522×176 cm) enhance exterior charm while ensuring ample natural ventilation and daylight.

First Floor Details

The first floor offers a master bedroom (360×396 cm), two additional bedrooms (359×396 cm and 370×396 cm), attached toilets (180×230 cm, 182×230 cm), and an upper living area (524×468 cm). A balcony (522×176 cm) and a pebbled courtyard add a natural touch, bringing freshness and serenity to the home.

Design Essence

Every corner of this plan is structured with architectural clarity and luxury, combining modern aesthetics with practical functionality. The plan ensures cross ventilation, balanced circulation, and an ideal family-friendly layout suited for duplex villas and contemporary urban homes.
