Luxury Villa First Floor Ceiling Layout With Bedrooms and Lobby

This AutoCAD DWG first-floor ceiling layout belongs to a luxury residential villa, designed with detailed lighting and HVAC placement for a refined interior experience. The plan includes a Double Height Lobby (18'-2" x 28'-10"), Bedroom 1 (12'-3" x 17'-8"), Bedroom 2 (16'-1" x 12'-6"), Drawing Room (13'-0" x 17'-4"), and a Grand Foyer (4'-9" x 13'-10"), each marked with ceiling levels, grooves, and cove lighting profiles.

Both Toilet 01 (7'-3" x 10'-1") and Toilet 02 (11'-3" x 6'-6") feature geyser connections and shower zones, while the walk-in wardrobe (7'-3" x 12'-4") and dressing niche support premium comfort. The plan also includes a 6'-11" wide front balcony and 15'-3" x 7'-0" rear balcony, ensuring enhanced ventilation and outdoor leisure.

Ceiling levels are meticulously defined, such as LVL +3", +4", +7", +9" from BB, along with AC grills, coves, curtain grazers, and parametric light bands for atmospheric illumination—ideal for architects, interior designers, and MEP planners.
