AutoCAD Commercial Building Plan with Shop Hall and Structural Detail

This AutoCAD commercial building plan provides a complete multi-storey layout, including basement, ground floor, mezzanine, first and second floors, and third to sixth floors, making it ideal for architects, civil engineers, and design professionals. The site plan shows a 26 ft 6 in by 32 ft plot totaling 848 sqft, located on a 150 ft wide main road with a secondary 20 ft wide access road for smooth commercial movement. The ground floor includes two shops measuring 12 ft by 22 ft and 13 ft by 16 ft 6 in, supported by an internal staircase and passage area sized 16 ft 6 in by 10 ft. The plan also highlights projection areas of 214 sqft and 57 sqft on upper floors, providing extended usable spaces. The basement layout is fully defined with an approved footprint, making it suitable for storage or service utilities.

The upper floors include spacious hall layouts such as Hall 1 at 13 ft 6 in by 25 ft and Hall 2 at 14 ft 6 in by 20 ft 6 in, along with a 7 ft by 5 ft lift that ensures smooth vertical circulation throughout the building. The drawing also details R.C.C. structural elements, including 6 in by 18 in beams, 6 in thick slabs, and multiple 6 in by 9 in lintels placed across all floors for accurate execution. Window and ventilation sizes such as W1 at 5 ft by 4 ft, W2 at 4 ft by 4 ft, and vents like V1 at 3 ft by 1 ft 6 in are clearly marked, alongside a 3 ft 6 in by 8 ft gate on the ground level. With detailed block plans for each level and a complete schedule of areas, including a total covered space of 5483 sqft, this AutoCAD commercial building plan offers all the essential data needed for professional planning, approval, and construction.
