Residential Township Master Planning Layout with Road and Plot Design

This residential township master planning layout presents a complete urban development design featuring organized road networks, zoning clusters, and structured plot divisions. The layout highlights primary and secondary roads with smooth connections to major access points, ensuring efficient circulation throughout the township. Plot blocks are arranged symmetrically, with grid-based divisions that support housing, commercial pockets, and integrated community areas. The curved and straight road sections allow smooth flow between residential streets and the main transportation link shown at the top of the layout. The drawing also displays landscape corridors, open green buffers, and designated utility areas essential for balanced township growth.

Further detailing includes planning zones for residential clusters, vehicular movement routes, pedestrian connections, and potential community facility areas. The central spine road branches into organized loops, reducing traffic congestion and providing easy access to all sectors within the plan. Each zone is planned with logical transitions, supporting phased development, infrastructure coordination, and future expansion. This DWG file is ideal for architects, urban planners, civil engineers, and developers working on township-scale projects, offering a clear blueprint for creating functional, well-connected, and sustainable residential communities.
