Column Footing and Reinforcement Plan with 400x400 mm Details

This AutoCAD drawing provides a complete structural layout of column footings and reinforcement detailing for accurate construction execution. The design highlights 400x400 mm column bases with precise reinforcement spacing, ensuring strength and stability in load-bearing structures. Each footing includes detailed reinforcement bar arrangements, including Ø8 mm stirrups at 150 mm spacing and D13 mm main bars placed uniformly for structural balance. The drawing also outlines slab connections, support beams, floor-level measurements, and column alignment to guide engineers and builders during site implementation. Clear sectional views display depth dimensions, concrete cover thickness, bar placement, and foundation levels, helping professionals visualize the reinforcement assembly before construction begins. The layout also includes top and bottom reinforcement placement with exact measurements for height, foundation depth, and beam connections, ensuring compliance with standard structural design practices. This detailed structural plan is ideal for architects, civil engineers, contractors, and construction supervisors who require accurate reinforcement design for residential or commercial building projects.
