Collage Multi-Floor Door Window Hardware Schedule Drawing with Sizes

This AutoCAD DWG drawing presents a complete multi-floor door, window, and hardware schedule prepared for educational and institutional buildings. The file includes ground floor, first floor, second floor, and third floor plans with clear door and window tagging for dormitory rooms, toilets, kitchens, corridors, and service areas. Door types D1 to D5 include flush doors, flush doors with glass transom, louvered doors, and security doors with standard sizes such as 800 x 2100 mm, 900 x 2100 mm, 1000 x 2100 mm, and 1200 x 2100 mm, along with frame thickness, shutter material, and glass specifications. Window types W1 to W3 cover sliding glass windows and awning windows with widths around 1500 mm and 1800 mm, anodized aluminium frames, sill heights, and clear float glass details. Steel grill windows SG1 are shown with bar spacing, frame depth, and fixing levels. Booth panels B1 to B4 illustrate folding arrangements with opening widths up to 5200 mm and heights of nearly 2400 mm. The drawing also integrates a detailed door, window, and hardware schedule table defining quantities, finishes, locks, hinges, and accessories
