5 BHK Villa Section autocad Drawing 1 100 Scale 8950mm Roof Level

5 BHK Villa Section Drawing 1 100 Scale 8950mm Roof AutoCAD DWG presents comprehensive architectural sections, including Section 1, Section 2, and Section 3, with precise vertical and horizontal dimensions as referenced in. The drawing defines Gate Level 0mm, Ground Floor 1200mm, Level 1 at 5200m,m Roof Level at 8950mm, and Basement Level at minus 2300mm, ensuring accurate multi-level coordination. Structural heights up to plus 10.400 TOW, plus 9.500 TO, W, and 3.900 TOW are clearly marked. The layout illustrates the entrance foyer, parking passage, kitchen, bathrooms, gym, walk-in closet, store room, MEP services, staircases, roof access hatch, skylight, planter, pool, shower, and driveway, with a width of 3200mm. Overall building depth 11250mm and width 9200mm are shown with plot limit boundaries and bay dimensions 800mm, 3500mm, 3200mm, 2700mm, and 3250mm.
