Steel Repair Detail Sheet 6ft Repair Length Flange Plate Weld

This steel repair detail sheet 6ft repair length flange plate weld drawing presents structural repair detailing used for steel column and flange rehabilitation in structural construction projects. The drawing illustrates sectional repair details showing the removal of damaged flange portions and replacement using cover plates and filler plates. Structural repair components include 3 4-inch by 7-inch cover plates and 1-inch by 7-inch filler plates welded to restore the integrity of the steel member. The repair layout also specifies full penetration butt weld connections and repair angles such as L5 inch by 3 inch by 3 4 inch installed at each side of the flange repair zone. The repair length for the structural member is approximately 6 ft with a development length of about 1 ft 10 in, as indicated in the repair detail layout.
