Gym AC Point Details Layout 18ft 5in 12ft 11in 8 inch wall DWG

This AutoCAD DWG drawing presents detailed gym AC point details with precise layout planning and dimensional accuracy. The plan includes cassette AC placements aligned across the gym floor with repeated spacing of 18ft 5in between units and vertical clearances of 12ft and 11ft 6in, ensuring balanced airflow distribution. The drawing highlights key sections such as free weight area, heavy weight zone, reception desk, changing rooms, and workout spaces with clearly marked AC points. Additional dimensions like 2ft 1in, 13ft 9in, and 8ft 8in define internal spacing and circulation paths. An 8-inch wall construction detail is also included for structural clarity. The legend specifies electrical and HVAC symbols, including switchboards, lighting, AC units, and ventilation, ensuring professional execution. This gym AC point details DWG is ideal for architects, civil engineers, and designers seeking accurate AC layout drawing and cassette AC placement in gym HVAC DWG plan with real scale references.
