Corner Column Slab Reinforcement DWG With Punching Shear Dimensions

A detailed corner column slab reinforcement DWG presenting complete structural layouts with accurate dimensions and punching shear detailing. The drawing includes corner column detail with dimensions showing typical internal columns PS1, corner columns PS2, and edge columns PS3 with column size around 1600 units and reinforcement spacing such as 200 mm and 600 mm zones. Section views Section 01, Section 02, and Section 03 illustrate reinforcement placement, slab thickness, and link details like 4L T12 200 links, ensuring proper load transfer between slab and column. The sheet also covers punching shear slab detail DWG drawing with flat slab reinforcement without drop for top and bottom layers, continuous slab layouts, and cantilever slab configurations. Additional details include trimming of slab openings, anchorage lengths, and reinforcement orientation for structural safety. This corner column slab reinforcement detail DWG file provides clear annotations, measurement references, and construction-ready detailing for accurate execution.
