Wooden Door DWG with Wall and Frame Sectional Construction Details

This AutoCAD Wooden Door DWG file offers a complete set of sectional construction details for architectural and interior projects. The drawing illustrates frame joints, fiber insulation layers, door panel composition, and wall section connections. Each segment includes precise material specifications such as OSB panels, gypsum boards, polyethylene membranes, and wooden framing elements. The plan showcases accurate dimensions, providing clarity on installation depth, fixing points, and reinforcement alignment, ensuring high precision during on-site execution.

The DWG drawing serves as a professional reference for architects, engineers, carpenters, and construction consultants involved in wooden structure design. It highlights moisture protection, vapor barriers, and acoustic insulation layers essential for durable and sustainable door installations. The sectional diagrams include clear annotations for wall thickness, structural supports, and inner insulation materials, making it ideal for both residential and commercial projects. This AutoCAD file can be customized and edited using AutoCAD, Revit, or SketchUp, enabling seamless integration into larger architectural models. It is a valuable resource for creating technically accurate and visually consistent wooden door designs in architectural blueprints.
