3D Skate Park CAD Layout with 65m Ramp Zone and Bowl Section

This detailed 3D skate park CAD layout presents a well-designed activity zone spanning approximately 65 meters in width, integrating multiple skating features suited for professional and recreational use. The left section showcases high gradient ramps, quarter pipes, flat decks, rail elements, and transition modules arranged in a balanced sequence for smooth movement. The central platform includes trick boxes, elevated levels, and safety railing components that reflect real-world skate park construction standards. The outer boundary walls and circulation paths are clearly defined, offering architects and designers a complete spatial understanding for planning and execution. A series of landscaped circular planters, seating edges, and pedestrian walkways enhance the overall visual alignment of the project.

On the right side of the model, a complete bowl section with curved depressions and flow lines is displayed, built with approximately 30 meters of continuous riding surface. Adjacent to this area sits a compact administrative block featuring a covered roof, entry structure, and perimeter gate. The file supports precise modeling workflows in AutoCAD, 3D Max, SketchUp, and Revit, making it ideal for architects, civil engineers, sports facility planners, and urban designers aiming to create high-performance skate park environments. This professionally structured DWG model is ready for design presentation, rendering integration, and conceptual development.
