Building Section Detail DWG with Structural and Size Dimensions

Explore a detailed building section DWG designed for accurate architectural and structural understanding. This AutoCAD drawing presents a sectional view highlighting key construction elements such as foundation, plinth level, floor slab, wall thickness, and roof structure. The section includes typical floor heights ranging from 3000 mm to 3500 mm, slab thickness around 120 mm to 150 mm, and wall thickness approximately 230 mm, ensuring proper proportion and clarity. It also illustrates door and window openings, vertical alignment, and level differences required for construction planning.
