This detailed DWG drawing provides a complete reinforcement layout for different shower stall configurations, including 36 in × 36 in and 32 in × 48 in units. The plan highlights required reinforcing locations for grab bars, identifying sidewall, backwall, and front-wall blocking zones with measurements such as 33–36 in maximum height and 27 in minimum height for proper mounting. The drawing also outlines optional seat installations with typical ANSI heights of 17–19 in, along with placement recommendations for handheld shower fixtures. In addition, the file includes reinforcement notes for showers used as the only bathing fixture in a dwelling unit, ensuring safe and stable installation of required grab bars.

The layout further illustrates the reinforcement requirements for glass-walled shower stalls, clarifying that glass and wet floor areas are not intended to receive grab bars, while adjacent conventional walls must be reinforced. Recommended door configurations are shown for hinged, sliding, and folding doors, each requiring a 32-inch minimum clear opening for accessibility. The drawing also includes reinforced areas behind toilets for the installation of fold-up grab bars, with specified zones such as 18 in minimum height and 12 in extended side coverage. These detailed measurements support accurate planning for safe and accessible bathroom design.

Detail of roof plan dwg file
