Three Floor Hospital Plan DWG with Layout and Dimensions desing

This three floor hospital plan DWG file provides a complete hospital layout drawing prepared for multi storey healthcare facility development projects The design includes ground first and second floor plans showing outpatient department emergency unit reception waiting area consultation rooms operation theatre intensive care unit patient wards pharmacy laboratory and administrative offices The hospital building autocad file also illustrates staircase lift cores service shafts corridor circulation and fire exit planning Wall thickness door window positioning and furniture layout are clearly marked for proper functional flow All areas are designed with accurate metric measurements including room length width corridor clearance and structural grid spacing
