Health Centre Site Layout Plan with Sections Rooms Parking Landscape

This Health Centre Design Plan presents a complete site layout prepared in AutoCAD DWG format, showing detailed zoning, circulation, and functional planning. The drawing includes outpatient rooms, consultation chambers, diagnostic units, waiting areas, pharmacy space, staff rooms, toilets, corridors, emergency access, and administration zones. The site covers an approximate built-up area of 4200 square meters, with internal room sizes ranging from 12 square meters to 35 square meters. The layout also displays parking bays, entry and exit routes, pedestrian pathways, boundary lines, landscaping zones, and green buffers. Elevations, sectional views, and front profiles are provided to support structural and architectural coordination.
