Medical Warehouse and Cold Storage Plan with Racks and Circulation

This AutoCAD DWG drawing presents a complete medical warehouse and cold storage facility layout prepared for pharmaceutical storage and distribution operations. The plan includes main storage areas, reception zone, quarantine section, cold chamber with controlled temperature range of 2°C to 8°C, narcotics storage, deposit rooms, and generator area. Metal storage racks measuring 1.00 m x 1.20 m are systematically arranged to maximize space utilization. The drawing also shows internal circulation corridors, administrative offices, a waiting hall, a computer room, dormitories, a kitchenette, and a security post. Floor level details such as NPT +0.75, NPT +3.30, and NPT +0.15 ensure accurate construction and vertical planning. Structural elements, roof coverage with calaminon sheets, and metal framework are clearly indicated in sectional and elevation views. This layout is based on the uploaded architectural documentation.
