Single Family House Drawing with Floor Plan Elevation and Section

This single-family house drawing is a complete AutoCAD architectural design prepared as a measured technical drawing for residential construction. The drawing set includes a detailed floor plan of a simple single-storey house without any basement, designed to sit partially or fully on natural ground level. Room layouts are clearly defined with internal wall dimensions, door and window positions, circulation spaces, and functional zoning of living area, bedrooms, kitchen, dining space, and bathrooms. All dimensions are provided between walls in metric units to specify accurate room sizes, wall lengths, and clearances, ensuring precise planning and execution.

The drawing also includes multiple elevation views and sectional details that illustrate building height, roof slope, plinth level, foundation depth, and structural layers. Structural detailing, such as footing sections, slab thickness, wall buildup, and level references are included to support construction coordination. This single-family house AutoCAD DWG file is suitable for architects, civil engineers, interior designers, and builders for residential planning, approvals, and site execution. The file is compatible with AutoCAD, 3D Max, Revit, and Google SketchUp workflows, making it a practical resource for single-family house design documentation and detailed architectural drawings.
