Water Tank Design Detail Drawing with RCC Section Pipes and Levels

This AutoCAD DWG file presents a clear and construction-ready water tank design detail focused on reinforced concrete structure and plumbing coordination. The drawing includes vertical and horizontal sections showing RCC column alignment, base concrete thickness, slab finish level, and wall junctions. Detailed plumbing elements illustrate PVC pipe routing, 90-degree bends, inspection cover position, pressure relief connection, and a minimum slope of 2 percent for drainage continuity. Fixing details for the roof sheet, holding screws, metal channel support, and developed plate section are clearly shown with accurate dimensions and level references.

The water tank design drawing is prepared for architects, civil engineers, and builders involved in residential and utility-related projects. It follows professional AutoCAD drafting standards and supports coordination with Revit, 3D Max, and SketchUp workflows. All components, such as RCC members, PVC pipe diameters, base concrete, masonry wall, and finished floor level, are fully annotated and scaled. This AutoCAD DWG file focuses strictly on drawing-related information and supports precise planning, detailing, and construction documentation through Cadbull subscription access.
