This AutoCAD drawing presents detailed swimming pool step construction drawings prepared for landscape and architectural coordination. The sheet includes a pool step details plan and typical section details at scale 1:15, clearly illustrating stepped profiles, tread and riser configurations, and waterproofing build-ups. Finished levels, such as FL plus 0.00, wall levels at minus 0.10, and base levels at minus 1.60, are accurately marked to ensure correct depth control and safe access. Dimensions including 300 mm, 250 mm, 200 mm, 50 mm, and variable step widths are shown to guide precise on-site execution. Stainless steel bars of 50 mm by 5 mm thickness at 250 mm spacing, ABS grates of 300 mm width and 30 mm thickness, and stone pavers with cement screed slope to drain are clearly detailed.

The drawing also covers typical pool edge details with LED lighting integration, waterproofing membranes, RC structure references, compacted sub-base, geo-textile filter fabric, and drainage discharge connections. Sectional details highlight step nosing, joint treatment, contraction joints with PVC dividers, and material transitions between pool finishes and surrounding landscape paving. Material and finishes legends specify components such as river-washed pebbles, stainless steel dowel bars, sand setting beds, and planting interfaces. These swimming pool step construction details provide architects, landscape designers, and builders with accurate dimensional references for execution, coordination, and quality control using AutoCAD drawings.
