Wall construction parapet details dwg file


Wall construction parapet details that includes a detailed view of layer- wall core polystyrene base material thickness of, layer-3 of wall of  "to the base of concrete of thickness, concrete chain, rebar steel rod ", stirrup for chain frame ", Hollow for fastening and assembly. pvc base material, round "so" for post-tensioning, steel plate, see detail pl, reinforcement rod square cms and much more of parapet wall details

File Type: DWG File ID: 114361

Uploaded by:

Presenting the broken author avatar :D Eiz Luna
