Plant second floor of office covering framing details dwg file


Plant second floor covering framing details that includes a detailed view of reception area, waiting area,  cabin, bottom false ceiling, computer lab, bottom of grid ceiling, counselling room and library, conference room, manager cabin with wood posts, joints, decking, grider pre-engineering, steel pipe column, play joints, existing floor joints, knee wall, steel pipe column, beam schedule details, dimensions details and much more of office project.

File Type: DWG File ID: 128133
