Cross section interior and exterior side walk construction details dwg file


Description

Cross section interior and exterior side walk construction details that includes a detailed view of seccion transversal de vereda interior, seccion transversal de vereda exterior, detalle de planta de veredas, polished concrete, gasket filled with asphalt 1 ", bruña parallel to the edge of the path, bruña parallel to the edge of the path and much more of side walk details.




File Type: DWG File ID: 137766

Uploaded by:


Eiz Luna
New-Zealand
