Office Centre Design Drawing with Plan Elevation and Section Details

This office centre design drawing is prepared in AutoCAD DWG format and provides complete architectural planning information for a public office facility. The drawing includes a detailed office plan showing reception or public attention area internal working spaces circulation zones and clearly divided work areas with accurate dimensions. Bathroom layout is integrated within the plan with proper access and spatial coordination. The architectural plan ensures efficient movement between public and staff zones while maintaining functional separation. The drawing set also includes front elevation side elevations and section details that explain building form wall heights roof profile and internal level relationships.
