2D Drawing Concrete Foundation With Beam Reinforcement Design AutoCAD File

2D Drawing Concrete Foundation With Beam Reinforcement Design AutoCAD File; the reinforcement details of the beam are as follows. Main straight bars: These bars are placed in the tension zone. In simply supported beams the main bars placed at the bottom and in case of cantilever beam these bars are placed at the top. The main function of this bar is to eliminate shear in beams.
