2400x3000 mm Bathroom Plan Layout with Section and Elevation Design

This 2400x3000 mm Bathroom Plan layout drawing presents a professionally drafted and fully dimensioned design suitable for residential and commercial projects. The file includes a detailed bathroom plan with accurate fixture placement, such as WC, wash basin, shower area, and door swing positions. The layout clearly defines wall thickness, internal circulation space, tile pattern layout, and sanitary alignment. Section detail and elevation views are incorporated to provide vertical construction information, highlighting floor finish levels, wall tiling heights, ventilation openings, and fixture mounting references. All measurements are precisely marked to ensure practical on-site execution and drafting clarity.

The 2400x3000 mm Bathroom Plan also contains a structured opening schedule with door and ventilator specifications for accurate installation. Section drawings illustrate plumbing alignment, floor slope direction, and ceiling references, while elevation drawings provide clear interior finish visualisation.
