Reinforced Concrete Chain Beam and Column Structural Detail.

This drawing shows a reinforced concrete chain beam and column structural detail prepared in AutoCAD files for building construction. The section illustrates the connection between the reinforced concrete column and the chain beam that supports masonry wall construction. The drawing clearly presents the structural column made with concrete strength of 3500 PSI integrated with the chain beam that distributes load across the wall structure. Brick masonry layers using fired brick blocks and mortar joints are shown attached to the reinforced concrete structure. The layout also illustrates the stepped masonry arrangement and the connection between the beam, column, and wall base foundation that supports the structure.
