Steel Slab Bridge Detail Plan Elevation with 6.00m Span Layout

The Steel Slab Bridge Detail drawing provides a comprehensive AutoCAD layout illustrating the structural design of a steel slab bridge with plan and elevation views. The drawing highlights the bridge deck slab arrangement with an approximate span of 6.00 m and a clear roadway width of about 4.00 m, designed for light vehicular movement. The plan layout shows the positioning of steel slab plates, deck alignment, and bridge edge beams that support the roadway surface. Elevation drawings display the structural configuration of the bridge, including steel slab thickness, beam supports, and abutment connections. Dimensional annotations clearly define slab spacing, deck width, and bridge span measurements to assist in accurate structural construction and planning.
