Closed Door Articulated Detail 15cm Spacing 12cm Height Section

Closed articulated door detail drawing showing precise interior elevation with uniform horizontal slat arrangement and 15cm spacing at top supports. The drawing clearly presents the closed door configuration with full height marked as 12cm and width indicated as A for proper dimensional reference. The elevation view highlights evenly spaced articulated panels that form a compact shutter system with a base locking strip and alignment supports. The sectional view on the side illustrates connection details, panel thickness, and fixing positions to ensure smooth operation and structural stability.
