5 Star Hotel CAD Drawing Showing Bedrooms Terrace and Elevation

This AutoCAD DWG file presents a 5 Star hotel CAD drawing with detailed floor layouts, bedroom arrangements, terrace restaurant, and elevation design for hospitality architectural planning. The drawing includes room distribution, circulation areas, structural alignment, and dimension details to support precise hotel design and space coordination. Architects, interior designers, and civil engineers can use this CAD file to integrate layouts, verify sections and elevation views, and plan hotel interiors efficiently. The CAD drawing provides proper scale reference, drafting clarity, and seamless integration into AutoCAD, Rivet, or 3D Max workflows for professional hotel design, documentation, and interior planning.
