Wooden House Rectangular Beam DWG Structural Detail with Sections

This AutoCAD DWG file provides detailed structural drawings of a wooden house project, focusing on rectangular beam connections and steel support systems. The drawing includes beam-to-column connection details, steel girder supports, slab bearing layouts, and reinforced concrete pedestal foundations. It illustrates vigueta spacing at 0.60 m, steel plate connections, welded angle joints, anchor bolt placements, and zinc sheet roofing support. Section views, elevation details, and support diagrams clearly explain load transfer mechanisms between beams, columns, and floor systems. Dimensional annotations specify beam widths, column sizes, pedestal depths, reinforcement spacing, and concrete cover thickness, ensuring accuracy for site execution and fabrication.
